Machine construction industry

ACMT experience focuses on the extremes in machine construction, from large 9000 ton presses for cement plate industry to small 100 mm rotor cryogenic helium turbo compressors.

Successful machine construction projects are dependent on accurate FEA. FEA can for example assess stiffness and predict changes in dimensions and tolerances affecting operations performance and wear.

To avoid costly redesigns, we work closely with the client and integrate specific needs. With FEA, production method and manufacturing costs can be integrated in the design process.

For our FEA analysis we use NASTRAN/FEMAP, a software with an extended set of capabilities, such as

    • Linear statics
    • Buckling
    • Normal modes and Eigenfrequencies
    • Heat transfer
    • Nonlinear
    • Dynamic behaviour

stress and stiffness analysis of a 9000t press for cement plate production: stress plot of part of exterior frames, half frames are calculated because of symmetry

9000t press

mechanical, rotordynamic and thermal analysis of 100mm diameter rotor for cryogenic helium compressor at 95.000 rpm and 75K operational temperature: stress plot of rotor
